5-30L Servo Palletizer
金彩汇Shanghai Guangzhi’s servo palletizer stacks 5-30L containers at 30 cycles/hour. ±0.5mm positioning, 1000kg capacity & AI pattern optimization. CE/ANSI certified.
- Brand： glzon
- Model： GZM_30L
Product Essence: Precision-Stacked Efficiency
Shanghai Guangzhi Automation’s 5-30L Servo Palletizer redefines container handling – achieving ±0.5mm positioning accuracy for buckets, drums, and cases at 30 cycles/hour. Combining military-grade servo control, AI-driven pattern optimization, and 1000kg payload capacity, it delivers 40% higher pallet density than conventional systems while reducing labor costs by 70% in chemical, food, and FMCG operations.
Core Technological Superiority
1. Ultra-Precision Motion Control
Twin Servo Arms:
Synchronized 6-axis motion (ISO 9283 path accuracy)
±0.5mm repeatability at 2m/s
Anti-Sway AI:
Active vibration damping for liquid containers
Prevents splashing (≤5% fill level fluctuation)
2. Intelligent Stacking Architecture
| Feature | Technical Value |
|---|---|
| 3D Vision Guidance | Container recognition in ≤0.3s |
| AI Pattern Engine | 30% denser stacking vs. conventional |
| Auto Pallet Switching | Continuous operation (no downtime) |
| Tool-Free Gripper Change | <90 sec for container format switch |
3. Heavy-Duty Performance
1000kg Payload Capacity:
Handles 8×30L drums per cycle
Carbon fiber reinforced arms
24/7 Readiness:
金彩汇IP67-rated joints (dust/washdown proof)
Predictive bearing wear monitoring
Technical Specifications
| Parameter | Standard Model | Hygienic Model |
|---|---|---|
| Container Range | 5-30L (Ø150-400mm) | 5-30L |
| Max Payload | 1000kg | 800kg |
| Throughput | 30 cycles/hour | 25 cycles/hour |
| Positioning Accuracy | ±0.5mm | ±0.5mm |
| Pallet Size | 1200×1000mm | 1200×1000mm |
| Max Stack Height | 2.5m | 2.2m |
| Power | 480V/60Hz, 8.5kW | 480V/60Hz, 7.2kW |
| Air Supply | 0.6MPa @ 60L/min | 0.6MPa @ 50L/min |
| Footprint (L×W) | 3500×2800mm | 3500×2800mm |
Industry-Specific Engineering
Chemical & Lubricants
金彩汇Explosion-proof option (ATEX Zone 2)
Static-dissipative grippers (<10⁶ Ω)
Food & Beverage
金彩汇FDA-grade UHMWPE contact surfaces
CIP washdown (IP69K)
FMCG
Mixed-SKU pattern recognition
Fragile item force control (5-50N)
Smart Control Ecosystem
15" HMI with Digital Twin
金彩汇Real-time simulation:
Pallet stability analysis
Energy consumption monitoring
金彩汇Collision avoidance mapping
金彩汇Pattern library:
金彩汇200+ preset configurations (e.g., pinwheel, brick)
金彩汇Auto-learns new container geometries
Industry 4.0 Integration
OPC UA communication with WMS/ERP
Predictive maintenance alerts:
金彩汇Servo motor temperature
Belt tension deviation
Cycle time degradation
Operational Impact
US Chemical Plant Case:
Challenge: 50% labor cost for stacking 20L solvent drums
Solution金彩汇: ATEX servo palletizer with anti-sway AI
Results:
▶ 70% labor reduction
▶ Zero drum damage (vs. 3% manual handling loss)
▶ ROI in 14 months
Global Compliance & Upgrades
Certifications:
金彩汇CE EN ISO 10218-1
金彩汇ANSI/RIA R15.06
金彩汇ISO 13849 PLd
Value Engineering:
40% Energy Savings: Regenerative drives capture braking energy
Modular Upgrades:
Module Function Vision Inspection Label orientation check Weight Verification ±0.1kg load cell per gripper AR Remote Assist HoloLens-guided troubleshooting Carbon Tracker ISO 14064 emission reporting
Support & Service
24/7 Global Robotics Support:
Remote diagnostics via VPN-secured IIoT
Critical Spares Dispatch ≤48h:
Servo drive units
Carbon fiber grippers
金彩汇Vision cameras
Lifetime cycle optimization
