金彩汇High-speed filling system for honey, pastes, and mayonnaise. Features viscosity-adaptive technology, food-grade design, EHEDG/FDA compliance, and 50 bottles/minute throughput.
Multi-Viscosity Bottling System for Honey, Pastes & Mayonnaise
Food-Grade Precision • 50 Bottles/Min • ±0.5% Accuracy • CIP/SIP Ready • EHEDG/FDA Certified
| Parameter | HF-5100 (Standard) | HF-5200V (High-Viscosity) | HF-5300P (Pharma-Grade) |
|---|---|---|---|
| Capacity Range | 50ml-5L (±0.5%) | 50ml-5L (±0.8%) | 50ml-5L (±0.3%) |
| Throughput | 1-50 Bottles/Min | 1-45 Bottles/Min | 1-40 Bottles/Min |
| Accuracy | ±0.5% Volumetric | ±0.8% | ±0.3% |
| Viscosity Range | 100-500,000 cP | 5,000-2,000,000 cP | 50-1,000,000 cP |
| Product Compatibility | Honey • Mayonnaise • Nut Butters • Cosmetic Pastes • Medical Ointments | Molten Chocolate | Sterile Gels |
| Filling Technology | Servo Piston + Mass Flow Meter<br>• 0.1ml Resolution<br>• Real-Time Density Compensation<br>• Flow Rate: 120L/min | Progressive Cavity Pump | Peristaltic Pump (FDA) |
| Temperature Control | PID-Heated Path (20-80°C)<br>±0.5°C Accuracy<br>Auto-Viscosity Adjustment | Same + Jacketed Hopper | Peltier Cooling System |
| Material Contact | 316L EP (Ra<0.4μm) | Hardox 500 + PTFE Coating | Glass-Lined Path |
| Anti-Stick System | NanoGlide™ Coating:<br>• Contact Angle >150°<br>• 0% Product Adhesion<br>• FDA 21 CFR Compliant | Same | Ultrasonic Vibrator |
| Cleanability | CIP/SIP Ready:<br>• 8-min Cycle<br>• ATP<3 RLU Validation<br>• Tool-Free Disassembly | Same | VHP Sterilization |
| Container Types | Glass/PET/PP Bottles • Jars • Tubes<br>Neck Size: 15-80mm<br>Cap Compatibility: Screw • Press • Flip-Top | Same | USP Containers |
| Changeover Time | <90s (Quick-Change Kits) | <120s | <60s |
| Power | 380V/50Hz, 5.5kW | 380V/50Hz, 7.2kW | 380V/50Hz, 4.8kW |
| Certifications | CE, EHEDG EL Class I | FDA 21 CFR 110/117 | ISO 22000:2018 |
Performance Validation:
| Product | Viscosity | Accuracy | Residual |
|---|---|---|---|
| Acacia Honey | 10,000 cP | ±0.42% | <0.3ml |
| Mayonnaise | 80,000 cP | ±0.58% | <0.5ml |
| Almond Butter | 250,000 cP | ±0.73% | <0.6ml |
| Technology | Function | Certification |
|---|---|---|
| PTFE Nano-Coating | Laser-Applied 50μm Layer | FDA 21 CFR 175.300 |
| Air-Knife Purge | 40bar Intermittent Blowoff | EHEDG Test Method |
| Vibrational Agitator | 60Hz Ultrasonic Resonance | ISO 14159 |
1. Bottle Infeed → 2. Auto-Decapping (Existing Containers) → 3. Pre-Heating (20-60°C) → 4. Precision Filling (±0.5%) → 5. Air-Knife Clean Neck → 6. Torque Capping (2-20 N·m) → 7. Weight Verification → 8. Labeling
Max Speed: 50 bottles/min (100ml Honey)
Versatility & Hygiene
► Universal Viscosity Handling: | **Product** | **Viscosity** | **Technical Solution**| |--------------------|-----------------|--------------------------------| | **Runny Honey** | 5,000 cP | Standard Piston | | **Thick Mayo**| 150,000 cP | Heated Shear Nozzle | | **Nut Butter**| 500,000 cP | Progressive Cavity Pump | ► Zero-Cross-Contamination: 1. Isolated Product Paths 2. <0.1ppm Carryover Guarantee 3. Color-Coded Change Kits ► Food-Safe Design: - EHEDG EL Class I Certified - Electropolished Surfaces (Ra<0.4μm) - 3° Drainage Slope
► EHEDG EL Class I (Certificate #EH-2024-HF55) ► FDA 21 CFR 110 (Current Good Manufacturing Practice) ► ISO 22000:2018 Food Safety
金彩汇"After implementing HF-5200V:
Output: 22 → 50 Bottles/Min (+127%)
Product Waste: 4.8% → 0.15%
Changeover Time: 15min → 90s
ROI Period金彩汇: 5 months"
APPLICABLE BARREL TYPE
