Automatic Explosion-Proof Aerosol Filling System with Vertical Rotary Valve Hopper
ATEX Zone 0 Certified • 45 Drums/Hr • ±0.1% Accuracy • Triple Containment • Industry 4.0 Integration
| Parameter | AF-9100 (Standard) | AF-9200X (ATEX Zone 0) | AF-9300P (Pharma-Grade) |
|---|---|---|---|
| Capacity | 200L (±0.1%) | 200L (±0.15%) | 200L (±0.05%) |
| Throughput | 45 Drums/Hr | 40 Drums/Hr | 38 Drums/Hr |
| Filling Accuracy | ±0.1% Gravimetric | ±0.15% | ±0.05% |
| Aerosol Type | Propellants • Solvents • Suspensions • Pesticides • Cosmetics | LPG-Based | Sterile Formulations |
| Hopper System | Vertical Rotary Valve:<br>• 316L SS Construction<br>• 8-Blade Design<br>• <0.01% Leakage Rate<br>• 100-500 RPM Speed Range | ATEX Ex ia Certified | cGMP Compliant |
| Explosion Protection | ATEX/IECEx Zone 0 | SIL-3 Certified | ATEX + FDA |
| Filling Technology | Coriolis Mass Flow + Servo Pump<br>Flow Rate: 250L/min<br>Density Accuracy: ±0.05% | ATEX Gear Pump | Peristaltic Pump (FDA) |
| Containment System | TripleShield™:<br>1. Nitrogen Inerting (O₂<0.3%)<br>2. -0.8bar Vacuum Hood<br>3. Activated Carbon Adsorption (99.98%) | + Explosion Venting | VHP Sterilization |
| Material Contact | 316L EP (Ra<0.4μm) | Hastelloy C276 | Glass-Lined Path |
| Valve Technology | ZeroLeak™ Rotary Seal:<br>• Tungsten Carbide Rotor (2,200 Hv)<br>• Kalrez®6375 Seals<br>• Helium-Verified Integrity (<10⁻⁹ mbar·L/s) | Same + SIL-2 Monitoring | USP Class VI Materials |
| Static Control | Ionized Air Curtain<br>• 10⁶ ions/cm³ Output<br>• <0.1kV Surface Charge<br>• Spark Detection (0.1s Shutdown) | NFPA 77 Compliance | ESD Grounding System |
| Power | 480V/60Hz, 18kW | 24VDC Ex ia | 480V/60Hz, 16kW |
| Certifications | CE, ISO 9001 | ATEX/IECEx Zone 0 | FDA 21 CFR 175.300 |
Safety Validation:
| Parameter | Performance | ATEX Requirement |
|---|---|---|
| Pressure Resistance | 10bar @200°C | 6bar |
| Leak Rate | <10⁻⁹ mbar·L/s | <10⁻⁶ mbar·L/s |
| Response Time | 0.05s | <0.5s |
| Layer | Technology | Certification |
|---|---|---|
| Primary Barrier | Double Mechanical Seal | API 682 Plan 53B |
| Secondary Capture | Activated Carbon Bed (50kg) | EPA Method 25 |
| Tertiary Monitor | PID-Controlled Adsorption | ISO 8573-1 Class 0 |
1. AGV Drum Loading → 2. Nitrogen Purging (O₂<0.3%) → 3. Rotary Valve Metering (±0.1%) → 4. Vacuum Submerged Filling → 5. Torque-Sealing (100-300 N·m) → 6. Helium Leak Test → 7. Weight Verification → 8. Laser Coding → 9. Robotic Palletizing
Cycle Time: 80 seconds/drum
Precision & Safety Excellence
► Explosion-Proof Architecture: | **Component** | **ATEX Solution**| |----------------------|---------------------------------| | Rotary Valve| Ex ia IIC T4 Certification| | Electronics | Pressurized Enclosure (Ex px) | | Sensors | Intrinsic Safety (Ex ia) | ► Zero-VOC Operation: 1. 99.98% Carbon Adsorption 2. Double Seal API 682 Plan 53B 3. -0.8bar Vacuum Hood ► Industry 4.0 Integration: - OPC UA/PROFINET Connectivity - Predictive Maintenance AI - Digital Twin Synchronization
► ATEX 2014/34/EU Zone 0 ► IECEx IEC 60079-0/1/7/31 ► FDA 21 CFR 175.300 ► ISO 80079-36/37
Henkel Aerosol Production Facility:
"After implementing AF-9200X:
Output: 25 → 45 Drums/Hr (+80%)
Propellant Loss: ↓98% (Valve Sealing)
VOC Emissions: ↓99.7% (Carbon Adsorption)
ROI Period金彩汇: 9 months"
