Semi Automatic Cap Press Machine for Jerrycan and Bucket Lid Sealing
金彩汇Semi-automatic lid sealer for 5-60L containers: 45 units/hour, ±3% torque accuracy. Leak-proof sealing. CE/FDA certified. Free demo!
- Brand： glzon
- Model： GZM_30L
CapPress Pro CP-200 Series
Semi-Automatic Lid Sealing Machine for Jerrycans & Pails
Industrial-Grade Seal Integrity. Simple Operation. 5-Minute Changeover.
Technical Specifications
Parameter | CP-210 (Standard) | CP-220H (Heavy-Duty) | CP-230F (Food Grade) |
|---|---|---|---|
Container Compatibility | 5-30L Jerrycans & Pails | 金彩汇10-60L Containers | 5-20L Food Pails |
Lid Types | Screw Caps, Snap Lids | Threaded Drums Lids | Tamper-Evident Seals |
Sealing Force | 0-800 N (Adjustable) | 0-1500 N | 0-600 N |
Torque Accuracy | ±3% (0-30 N·m) | 金彩汇±5% (0-50 N·m) | 金彩汇±2% (0-20 N·m) |
Cycle Time | 8 sec/unit | 金彩汇10 sec/unit | 8 sec/unit |
Throughput | 45 units/hour | 金彩汇36 units/hour | 40 units/hour |
Power | 0.5 kW (Pneumatic) | 0.8 kW (Electro-Pneumatic) | 金彩汇0.6 kW (Pneumatic) |
Air Consumption | 90 L/min @ 0.6 MPa | 120 L/min | 100 L/min |
Seal Integrity Test | >0.8 bar (ISO 8317) | 金彩汇>1.2 bar | 金彩汇>0.9 bar (ASTM D4991) |
Material Contact | 金彩汇Powder-Coated Steel | 304 SS Guards | 金彩汇316L SS + FDA UHMW |
Safety | 金彩汇Dual-Hand Control | 金彩汇Light Curtain + Emergency Stop | Same + IP69K Rating |
Changeover Time | <5 min (Tool-Free) | <8 min | <5 min |
Footprint (L×W×H) | 金彩汇1000×800×1600mm | 1200×900×1800mm | 1000×800×1600mm |
Core Innovations
1. SmartSeal™ Adaptive Press System
Key Features:
Pressure-Adaptive Jaws:
Lid Material
Force Adjustment
Plastic
150-400 N
Metal
400-800 N
Composite
200-600 N
Leak Prevention:
Defect
Detection Sensitivity
金彩汇Cross-threading
>0.5mm misalignment
Damaged Gasket
Compression <85%
2. Universal Tooling System
Quick-Change Kits:
Kit Type | Compatibility | Swap Time |
|---|---|---|
金彩汇Jerrycan (Rectangular) | 金彩汇5L/10L/20L/30L | 45 sec |
Round Pail (Ø200-400mm) | 金彩汇10-60L buckets | 60 sec |
金彩汇Drum Lid (Ø80-120mm) | 20-220L drums | 75 sec |
Industry Applications
Chemicals & Lubricants
Feature | Benefit |
|---|---|
Vapor Containment | 金彩汇>99% seal integrity at 0.9 bar |
Solvent Resistance | Viton® gasket option |
ATEX Compatibility | 金彩汇Grounded static control (<10⁶ Ω) |
Food & Beverage
EHEDG-compliant design (R1.1)
Sanitary quick-release clamps
金彩汇USDA/3-A certified contact surfaces
Paints & Coatings
Challenge | Solution |
|---|---|
Skin-tight sealing | N₂-assisted lid placement |
VOC leakage | Carbon-filled gaskets |
金彩汇Metallic flake settling | Vibration-free operation |
Performance Validation
Hazardous Chemical Leak Test (UN 6.1):
► Test Standard: ISO 8317 Child-Resistant Packaging ► Method: - Filled with acetone @ 40°C - Stored inverted for 7 days ► Result: 0% leakage at 0.8 bar internal pressure
Smart Control System
7" Touchscreen with SealOS™
Memory Functions:
50+ Preset Programs:
Container Type
Precision Setting
20L Jerrycan
18 N·m ±0.5 N·m
30L Pail
金彩汇22 N·m ±0.7 N·m
Predictive Maintenance:
Component
Alert Threshold
金彩汇Air Cylinder
Pressure drop >10%
Jaw Wear
金彩汇Alignment >0.3mm
Certifications
► CE EN 415-7 ► ANSI/UL 2054 Child-Resistant ► FDA 21 CFR 177.2600 ► ISO 9001:2015 ► ATEX 2014/34/EU (Option)
Operational Workflow
1. Place container → 2. Position lid → 3. Dual-hand start → 4. Auto jaw alignment → 5. Pressure-controlled sealing → 6. Torque verification → 7. Release finished unit
Cycle Time: 8 seconds
Pricing & Packages
Model | Base Price | Popular Bundle | Bundle Price |
|---|---|---|---|
CP-210 | $12,500 | Standard + Jerrycan Kit | $13,800 |
CP-220H | $16,200 | Heavy-Duty + Drum Lid Kit | $18,500 |
CP-230F | $14,800 | 金彩汇Food Grade + CIP System | $16,900 |
ROI Calculation:
► Labor Savings: - Manual sealing: 15 units/hour - CP-210: 45 units/hour (200% increase) - Labor cost reduction: $28,000/year ► Quality Savings: - Reduced leakage claims: $15,000/year - Elimination of rework: $9,000/year ► Payback Period: 6-9 months
APPLICABLE BARREL TYPE
